| Specification | |
|---|---|
| 1) Dielectric Antenna | |
| Center Frequency | 1575.42 MHz±3 MHz |
| V.S.W.R | 1.5:1 |
| Band Width | ±5 MHz |
| Impedance | 50 ohm |
| Polarization Type | R.H.C.P |
| 2) LNA/Filter | |
| LNA Gain(w/o cable) | 30 dB Typical |
| Noise Figure | 1.5 dB |
| DC Voltage | 2.2~5 V |
| DC Current | 5~15 mA |
| 3) GSM Antenna | |
| Frequency Range | 824~894 MHz 880~960 MHz 1710~1990 MHz 1920~2170 MHz |
| V.S.W.R | 2.0:1 |
| Impedance | 50 ohm |
| Typical Gain(w/o cable) | 2 dBi |
| Polarization Type | Vertical or Horizontal |
| 4) Mechanical | |
| Size | D78*15mm |
| Mounting | Screw |
| Housing | Black |
| Package | 120*95*30mm |
| Optional Cable | RG174, 3m or others |
| Optional Connectors | SMA/MCX/SMB/BNC or others |
| 5) Environmental | |
| Working Temp. | -40℃~+85℃ |
| Humidity | 55%~75%RH |
| Waterproof | IP67 |
